standard classification includes with short taper HSK 63 with blade ISO 40 and ISO 50 taper shank ( conform DIN 69781 or JIS B 6339 (MAS BT)) and Razor ISO 50 taper shank ( meet DIN 2080) of the machine tool clamping elements . In addition to the classic tool clamping system, the scope of supply also includes a modular system ( with interchangeable tool heads ) shank , hydraulic chuck and Shrinkfit holders .

Pramet new machine is also provided within the required complex installations other types of holders. Machining performance also depends on the quality of the tool clamping . Thus, compared to general- FMH2 taper shank for milling nested select fixed FMH1 taper shank will be better. FMH4 taper shank is clamped all the width of the disc cutter generic solutions.

for the most common tool shank Weldon chuck is slowly being replaced by a modular system . The advantage of the modular system is not only more accurate , but chuck and tool kit tool overhang is shorter .

tool runout is a solid tool and drill limits . Therefore , CC2 collet series has been improved and is classified adds high precision collet type HP . We can provide you with higher precision Shrinkfit holders and hydraulic chuck.

provided collets (CC2) and Weldon chuck, hydraulic chuck and Shrinkfit holders can achieve higher quality homeostasis. Maximum number of revolutions of the equilibrium and rotating masses decisions. For more information, please refer to the technical part of the clamping system directory .
